This page is incomplete. Lot's of tests not described. Screenshot for rules is missing.

Preferences > Data Validator

source:trunk/resources/images/preferences/validator.svg An OSM data validator that checks for common errors made by users and editor programs.


Following four general settings are available:

Use ignore list
enable/disable the use of the ignore list (default: enabled)
Advance preference: validator.ignore
Use error layer
enable/disable the creation of a validator layer highlighting the problematic objects (default: enabled)
Advance preference: validator.layer
Show informational level
enable/disable tests on informational level know as "Other" (default: disabled)
Advance preference: validator.other
Show informational level on upload
enable/disable tests on informational level on upload (default: disabled)
Advance preference: validator.otherUpload

All check boxes below are settings which test should be run on which action with a check box on the left for manual runs, On demand, and On upload on the right side.

By default, all error and warning tests are active.

  1. If you are a OSM newbie and encountered validation error about objects you haven't touched, please ignore these messages for now.
  2. Validator can be wrong or incomplete about all tagging practices. Don't fix errors when you aren't sure something is really wrong.
  3. First, refer to Validator panel - how to use validator

new screenshot

The fourth column contains also (video) explanations. The table is incomplete.

Type Message What is checked Additional help Autofix
Addresses errors in Addresses and Relation:associatedStreet.

Advanced preferences:
validator.addresses.max_duplicate_distance (default: 200.0)
validator.addresses.max_street_distance (default: 200.0)
source:trunk/resources/images/data/warning.svg House number without street objects that have an addr:housenumber tag, but neither addr:street nor addr:place. The street name can also be provided using an associatedStreet relation or on interpolation way. Add the missing street name information. no
source:trunk/resources/images/data/warning.svg Duplicate house numbers two members of an associatedStreet relation have the identical house number. It is possible with a low chance. no
source:trunk/resources/images/data/warning.svg Multiple street names in relation name tag of an associatedStreet relation matches the name tags of the members with role street and the addr:street tag of the members with role house. no
source:trunk/resources/images/data/warning.svg House number too far from street the houses of an associatedStreet are far away from the corresponding street. Verify that the house really belongs the the street that is given by the relation. no
source:trunk/resources/images/data/warning.svg Multiple associatedStreet relations an object is in more than one associatedStreet relation. no
API Capabilities errors against API capabilities
source:trunk/resources/images/data/error.svg Way contains more than … nodes. It should be replaced by a multipolygon
source:trunk/resources/images/data/error.svg Way contains more than … nodes. It should be split or simplified
Barriers and entrances errors in Barriers and Key:entrance.
Coastlines Coastline are correct.
source:trunk/resources/images/data/error.svg Reversed coastline: land not on left side coastlines that are not counter-clockwise or that are otherwise misplaced (coastline misused as inland lake) Reverse coastline
source:trunk/resources/images/data/error.svg Unconnected coastline: coastline ways do not form closed loops coastlines ways that are not connected to the end of other coastline ways
source:trunk/resources/images/data/error.svg Unordered coastline: coastline ways are not connected start-to-end coastline ways of which either the start is not connected to the end of another coastline or the end is not connected to the start of another coastline Reverse coastline
Conditional Keys usage of *:conditional tags. Imprecise rules covered at osm wiki page "Conditional restrictions"
Connectivity Relations Validates connectivity relations
source:trunk/resources/images/data/error.svg Connectivity tag missing comma between optional and non-optional values no
source:trunk/resources/images/data/error.svg Connectivity tag contains unusual data no
source:trunk/resources/images/data/warning.svg Connectivity relation without connectivity tag no
source:trunk/resources/images/data/warning.svg Inconsistent lane numbering between relation and member tags no
source:trunk/resources/images/data/warning.svg Multiple via roles only allowed with ways no
source:trunk/resources/images/data/warning.svg Relation member is missing a lanes or *:lanes tag no
source:trunk/resources/images/data/warning.svg Relation should not contain mixed via ways and nodes no
source:trunk/resources/images/data/warning.svg This connectivity may already be implied no
Crossing barriers / boundaries / ways
source:trunk/resources/images/data/warning.svg Crossing ways ways (with highway/railway/waterway tags) that cross in same layer with no crossing node 1. (video) usually you need to add a common node or
2. add appropriate Key:layer (and possibly Key:bridge or Key:tunnel)
source:trunk/resources/images/data/warning.svg Crossing barrier/building barrier crossing a building in same layer with no crossing node no
Duplicated nodes Advanced preference:
validator.duplicatenodes.precision: rounding precision in degree (default: 1e-6 since r17612, 1-e7 before)
source:trunk/resources/images/data/error.svg Duplicated nodes no nodes in the very same location Merge the nodes into only one, adding the properties from all nodes to the merged one
Duplicated relations no relations with same tags and same members with same roles.
Duplicated ways no ways with same node coordinates and optionally also same tags.
Duplicated way nodes ways with identical consecutive nodes.
source:trunk/resources/images/data/error.svg Duplicated way nodes ways contain no loop edges (i.e., a single step from a node to itself) Split the way, and delete the way consisting of the loop edge.
Highways semantic checks on highways.
Internet tags errors in internet-related tags
Lane tags lanes:* tags, see Lanes
Long segments long way segments, which are usually errors

Advanced preference: validator.maximum.segment.length: maximum segment length in meters (default: 15,000)
source:trunk/resources/images/data/warning.svg Long segments - Very long segment of … kilometers way segment length above certain configured value For real world objects it makes sence to add some way nodes. no
Tag checker (MapCSS based) different kind of checks based on MapCSS, including external rules. See Tag checker rules tab and detailed description below.
Multipolygon multipolygons are valid.
source:trunk/resources/images/data/warning.svg Style for outer way mismatches Within a multipolygon relation, one of the tags of the relation and the outer ways is shared but with different values Copy relation related tags to the relation itself no
source:trunk/resources/images/data/warning.svg Style for inner way equals multipolygon Within a multipolygon relation, one of the tags of the relation and the inner ways is shared and has the same value Remove tag from inner way no
source:trunk/resources/images/data/other.svg No style in multipolygon relation The multipolygon relation is missing a tag describing what it represents For a building, add building=yes to the relation etc. no
Missing name:* translation finds multilingual objects whose name attribute is not equal to some name:* attribute and not a composition of name:* attributes, e.g., Italia - Italien - Italy.
Opening hours syntax correct usage of the opening hours syntax. common OH examples common mistakes complete OH spec
Enable strict mode. even stricter rules, disabled by default

validator.OpeningHourTest.strict (default: false)
Overlapping ways a connection between two nodes is not used by more than one way.

Advanced preferences:
overlapping-ways.ignored-keys - list of ignored keys
overlapping-ways.ignore-layer (default: false)
overlapping-ways.only-known-linear (default: true)
(video) Using selection, split and middle mouse
source:trunk/resources/images/data/error.svg Overlapping high-/rail-/waterways two ways with highway=*, railway=* or waterway=* that share the same nodes no
source:trunk/resources/images/data/error.svg Way contains segment twice no
source:trunk/resources/images/data/warning.svg High-/Rail-/Waterway shares segment with linear way a way with highway=*, railway=* or waterway=* sharing consecutive nodes with another open way no
source:trunk/resources/images/data/other.svg High-/Rail-/Waterway shares segment with other way a way with highway=*, railway=* or waterway=* sharing consecutive nodes with a closed way or multipolygon Depending on the mapping style and the tags of the involved area these overlaps are ok or not. It definitively makes selecting the objects and distinguishing between them harder no
source:trunk/resources/images/data/other.svg Ways share segment no
Power lines - nodes in power lines/minor_lines that do not have a power=tower/pole/portal tag
- nodes where the reference numbering not consistent
- ways where are unusually long segments without line support feature
- ways where the line type is possibly misused

Advanced preferences:
validator.PowerLines.hilly_compensation (default: 0.2)
validator.PowerLines.hilly_threshold (default: 4.0)
Public Transport Route errors in public transport route relations
Relation checker errors in relations.
Almost right angle buildings buildings with an almost right angle.

Advanced preferences:
validator.RightAngleBuilding.maximumDelta (default: 10.0)
validator.RightAngleBuilding.minimumDelta (default: 1.0)
source:trunk/resources/images/data/other.svg Building with an almost square angle If the angle should be a right angle, orthogonalize the way. yes, #20038
Self-intersecting ways ways that contain some of their nodes more than once.
source:trunk/resources/images/data/warning.svg Self-intersecting ways a way crosses itself Remove the self-crossing, remove overlapping parts or split way
Sharp angles sharp angles on roads
Similarly named ways ways with similar names that may have been misspelled.
source:trunk/resources/images/data/warning.svg Similar named ways ways with very similar names, possibly a typo
Tag checker errors in tag keys and values.
Check property values misspelled property values. Uses the loaded tagging presets files for checking
source:trunk/resources/images/data/other.svg Presets do not contain property key the property key is in no preset Check the key or
Load the preset
source:trunk/resources/images/data/other.svg Presets do not contain property value the property value is in no preset Check the value or
Load the preset
Check for fixme. any property with the word "fixme" inside
source:trunk/resources/images/data/other.svg fixme Check if you can fix the issue or if it was fixed already. If so, remove the "fixme", otherwise do nothing. no
Turn-restrictions turn-restrictions are valid.
source:trunk/resources/images/data/error.svg No "from" way found
No "to" way found
No "via" node or way found
all necessary elements of a turn restriction relation are present. no
source:trunk/resources/images/data/error.svg More than one "from" way found
More than one "to" way found
More than one "via" node found
at most one way with role from and to and at most one node with role via in a turn restriction relation. no
source:trunk/resources/images/data/error.svg Cannot mix node and way for role "via" there is either a "via" node or multiple "via" ways, but not a mix of nodes and ways with role via. no
source:trunk/resources/images/data/error.svg The "from" way does not start or end at a "via" node.
The "to" way does not start or end at a "via" node.
The "from" and the first "via" way are not connected.
The "via" ways are not connected.
The last "via" and the "to" way are not connected.
the different parts of a turn restriction relation are connected. is also aware of oneway streets and considers parts unconnected, if they cannot be traveled in the intended order due to the oneway restriction. Make sure that consecutive member of a turn restriction relation are connected. (Ways must be connected end-to-end.) no
source:trunk/resources/images/data/warning.svg Unknown role the role for members of a turn restriction relation is either from, to (ways) or via (nodes and ways) no
source:trunk/resources/images/data/warning.svg Unknown member type only nodes and ways (and not relations) are members of a turn restriction relation. no
source:trunk/resources/images/data/warning.svg Superfluous turn-restriction as "to" way is oneway The turn restriction is not needed, because the corresponding turn would mean to enter a oneway street from the wrong side. Verify that the "from" and "to" ways are correctly assigned and delete the relation if it is indeed superfluous. no
Unclosed Ways ways which should be circular are closed.
source:trunk/resources/images/data/warning.svg Unclosed ways way types, which should be closed really are closed Close unclosed ways no
Unconnected highways / natural lands and landuses / power ways / railways / waterways a way has an endpoint very near to another way.

Advanced preferences:
validator.UnconnectedWays.node_way_distance (default: 10.0)
validator.UnconnectedWays.node_way_distance_railway (default: 1.0)
validator.UnconnectedWays.way_way_distance (default: 0.0)
source:trunk/resources/images/data/warning.svg Way end node near other highway End point of a way is very near to other ways Connect the ways or when really unconnected add noexit=yes tag to prevent further warnings no
source:trunk/resources/images/data/warning.svg Way end node near other way no
source:trunk/resources/images/data/other.svg Connected way end node near other way no
source:trunk/resources/images/data/other.svg Way node near other way no
Untagged and unconnected nodes untagged nodes that are not part of any way.
source:trunk/resources/images/data/warning.svg Unconnected nodes without physical tags -
No tags
Has key created_by or converted_by
Has key source
Has key watch
nodes not part of any way without tags or only created_by, converted_by, source or watch 1. If the node was created by yourself, you are to decide if to remove it otherwise
2. Download parent relations and contact mappers who added these nodes in unclear cases
source:trunk/resources/images/data/warning.svg Unconnected nodes without physical tags -
Has key note or comment or description
Has tag containing fixme
nodes not part of any way with only note, comment, description or fixme 1. If the node was created by yourself, you are to decide if to remove it otherwise
2. Download parent relations and contact mappers who added these nodes in unclear cases
Untagged, empty and one node ways untagged, empty and one node ways.
source:trunk/resources/images/data/error.svg Empty ways

One node ways
Invalid ways with zero or only one node 1. Look at the object's history
2. Remove the way (autofix)
source:trunk/resources/images/data/warning.svg Unnamed ways highway without name or ref Add name or ref if known or noname=yes if sure that the way does not have a name no
source:trunk/resources/images/data/warning.svg Untagged ways (commented!) ways without any tag (or only with comment, description, fixme or note) and without membership in a relation 0. if working with incomplete data, download parent relations
1. describe them correctly if you know this objects or
2. leave them until somebody describes them
source:trunk/resources/images/data/other.svg Unnamed junction highway with junction and without name or ref Add name or ref if known or noname=yes if sure that the junction does not have a name no
Way connected to Area ways connected to areas.
source:trunk/resources/images/data/warning.svg Way terminates on Area First/Last node of way connected with area Optionally, either continue the way, unglue it from area or add a tag describing an entrance. no
Wrongly Ordered Ways direction of water, land and coastline ways.
source:trunk/resources/images/data/warning.svg Reversed coastline: land not on left side

Reversed land: land not on left side
wrong way direction of natural=coastline

wrong way direction of natural=land
Reverse way direction no
Uncategorized Descriptions that need to be checked, updated and added to one of the categories above or MapCSS below
Check property keys misspelled property keys. See the words.cfg for file of misspelled property keys Replace wrong key with right one
Empty properties properties with empty values
source:trunk/resources/images/data/other.svg Key 'x' invalid. - ... illegal key combinations, names and similar issues
source:trunk/resources/images/data/other.svg Nodes with the same name two nodes have equal name
source:trunk/resources/images/data/other.svg Unknown property value proper use of tags If it is your new tag, it is a good idea to document it at the OSM-wiki (Any tags you like) no

Tag checker rules

This tab consists of two list and some buttons. On the left side all available rules are listed and on the right side all downloaded and local rules.

Available rules (left)

There is a search text box on top and below first the internal MapCSS rules and then the external ones are listed. Some more info about each item will be displayed in a tooltip when hovering the mouse over it. Items which are already on the Active rules list on the right side are highlighted with a different background color which changes if the item is enabled/disabled on the right side. To get items from the left to the right, select them and use the source:trunk/resources/images/preferences/activate-right.svg blue, right arrow head button between the lists. With the source:trunk/resources/images/dialogs/refresh.svg button at the bottom reloads the available rules list from JOSM (file).

Active rules (right)

Rules can be enabled/disable with the check box in front of each entry.
The three buttons on the right allow to:

  • source:trunk/resources/images/dialogs/add.svg manually add rules from url or local file
  • source:trunk/resources/images/dialogs/edit.svg modify selected entry
  • source:trunk/resources/images/dialogs/delete.svg delete items from the list

The source:trunk/resources/images/preferences/reset.svg reset button at the bottom resets the active rules to default, removing any manually added entry.

MapCSS-based tests

Type Message What is checked Additional help Autofix
Tag combinations
Deprecated features
source:trunk/resources/images/data/other.svg Overlapping areas areas overlap Remove overlapping only when really wrong. no
source:trunk/resources/images/data/other.svg Highway without a reference there is a ref tag for highways that are tagged tertiary. Not always required, see for instance Highway Optionally, add noref=yes no
Multiple values
Numeric values
Unnecessary tags

Advanced Preferences

More advanced preferences not described, yet.

  • validator.auto_reload_local_rules - whether to auto-reload local rules after file changes
  • validator.autozoom - whether to Zoom to problem, automatically
  • validator.check_assert_local_rules - whether to enable MapCSS assertions for local rules
  • validator.ignorelist - the ignore list
  • validator.ignorelist.version - format version of the ignore list

See also

Back to Preferences Dialog
Back to Main Help

Last modified 17 months ago Last modified on 2022-12-10T16:00:27+01:00

Attachments (3)

Download all attachments as: .zip

Note: See TracWiki for help on using the wiki.
