Geotagged images are displayed at wrong (rounded?) position

[brainsail]

What steps will reproduce the problem?

1. Open geotagged images
2. Open the track that was recorded with the same device as the photos

What is the expected result?

Image symbols should appear exactly on the track.

What happens instead?

Many image symbols are 10 - 20 m off the track. Looks like they are on a raster, as if the position was rounded too much.

Please provide any additional information below. Attach a screenshot if possible.

Repository Root: http://josm.openstreetmap.de/svn
Build-Date: 2015-03-02 02:30:58
Last Changed Author: Don-vip
Revision: 8109
Repository UUID: 0c6e7542-c601-0410-84e7-c038aed88b3b
Relative URL: ^/trunk
URL: http://josm.openstreetmap.de/svn/trunk
Last Changed Date: 2015-03-02 00:13:51 +0100 (Mon, 02 Mar 2015)
Last Changed Rev: 8109

Identification: JOSM/1.5 (8109 en) Linux Ubuntu 14.04.2 LTS
Memory Usage: 1381 MB / 3461 MB (1155 MB allocated, but free)
Java version: 1.7.0_75, Oracle Corporation, OpenJDK 64-Bit Server VM
Java package: openjdk-7-jre:amd64-7u75-2.5.4-1~trusty1
VM arguments: [-Djosm.restart=true, -Djava.net.useSystemProxies=true]
Dataset consistency test: No problems found

Plugins:
- buildings_tools (30955)
- terracer (30892)

[bastiK]

This is a problem of the recording device. If you think otherwise, please attach the gpx track and 1-2 images.

[anonymous]

the track

[anonymous]

The exif position has sufficient precision. Attached img_300.jpg and the the track.

[bastiK]

Yes, but it's not on the GPX track.

[anonymous]

I've found there are two different ways of decoding these coordinates. One is correct, the other is off.

1. exif-viewer.com

48,44.924128199999984N = 48.74873547
9,5.6574479999999738E = 9.0942908
matches the point in the track

<trkpt lat="48.7487355" lon="9.0942908">

<time>2015-03-28T13:58:22Z</time>

2. exifdata.com

48.748611 degrees N

9.094167 degrees E

This is where josm shows it.

I don't know anything about the format of coordinates in exif. The data in this image was encoded by Qt. I hope you can support this encoding.

[bastiK]

They include the position twice:

$ exiftool -v img_0300.jpg
...
  | 3)  GPSInfo (SubDirectory) -->
  | + [GPS directory with 4 entries]
  | | 0)  GPSLatitudeRef = N
  | | 1)  GPSLatitude = 48 44 55 (48/1 44/1 55/1)
  | | 2)  GPSLongitudeRef = E
  | | 3)  GPSLongitude = 9 5 39 (9/1 5/1 39/1)
JPEG APP1 (2990 bytes):
  + [XMP directory, 2961 bytes]
  | XMPToolkit = GStreamer
  | ExposureCompensation = 0/1
  | GPSLatitude = 48,44.924128199999984N
  | GPSLongitude = 9,5.6574479999999738E
...

The correct value as XMP metadata and again the incorrectly (rounded) in the standard EXIF format.

It isn't our problem that the metadata is inconsistent, this is simply broken. Given two values, I would rather rely on EXIF.

You can write a script that fixes the images files. Alternatively you may submit a patch that adds a workaround.
